Working Area (X*Y axis)

1500*2500MM( can be extended)

Cutting Thickness

0.5-200mm

Track Width

2000mm (can be extended)

Track Length

3000mm (can be extended)

Hole Cutting Thickness

0-55mm ( according to plasma power) ,

Vertical/Horizontal Guide Rail

high-precision linear guide

CNC Control System

Starifire

Plasma Power source

Hyperthem ,Huayuan ...

Plamsa Power (amp)

63a/100a/120a/160a/200a/300amp

Programming System

FASTCAM

Precise molding programming control software (can achieve small hole cutting function)

Motor Drive

Stepper Motor

Conveyor Towline

high-strength engineering plastic towline transmission

Speed Range

0- 3500 mm/min (continuously variable )

Power Supply

three phase 380V, 50HZ/60HZ

Driving Method

Single drive

Moving precision

0.01mm/step

Transmission

Rack and Pinion

LCD Dimension

7inch

Cutting Torch

Plasma or Flame or both

Gas Fuel for Flame Cutting

Oxygen, gas, acetylene, propane, liquefied gas

Cutting materials

mild steel , carbon steel ( flame cutting ), Iron, steel aluminum sheets, galvanized sheets, Titanium plates(plasma cutting )...all kinds of metal

Weight

200KG
