Loading capacity 50T

Size 13600x2500x4000mm

Chassis (I beam)

Top flange plate Material &thicknessQ345B  14mm

Bottom flange plate Material &thicknessQ345B  16mm

Middle flange plate Material Q345B

Thickness 8mm

Height 500mm

Side beam height Type  U steel

Height 16# U steel

Box height

Thickness 1.5mm

Height   2400mm

Plate type   Corrugated plate(upright type)

Floor         Material                    Carbon steel Q235

Thickness     3mm

 Floor type                    Checkered plate

Running mechanism

Axle Brand Factory standard

Type 13t

Number 3pcs

Rim Type 9.0-22.5

Number 12 pcs

Tire  Brand Triangle brand

Type 12R22.5

Number 12pcs

Suspension Mechanical suspension

Spring leaf Leaf width 90mm

Leaf thickness13mm

Layer/set 10 Layer

King pin Type Bolts type

Diameter 2  inch

Brake system Air tank 45L air tanks

Brake chamber 6 double spring brake chamber

ABS Without

Landing gear Brand JOST E100 brand

Type two speed 25t

Accessories

Spare tire carrier   2sets

Light  LED light

Voltage 24v

Receptacle 7 ways(7wire harness)and quick change type

Tool box One piece,1000x500x500mm

Paiting Polyurethane paint&anti-rust primer&sand blasting

Tools for trailer Head wrech ;spare wheel crank ;
