1

Dimensions(length*width*height)

13000×2500×3995(MM)

2

Estimated Tare Weight

15514KG

3

Payload

24486KG

Shell Of Tanker

1

Products

LPG, Butane , Propane

2

Fluidproperty

flammable

4

Design temperature

 to 50℃

5

Design pressure

1.61MPa

6

Corrosion allowance

1.0mm

7

Major materials of bearing pressure

Tanker body : Q345R , 12mm

End plate : Q345R , 14mm

Main Beam : Q345B

8

Filling weight per volume

9

Maximum filling weight

10

Compartments

One

11

Baffle inside the tank

14-off Aluminium bolted plate , thickness is 5mm

12

Shape

Cylindrical ; Ellipse head

Detection

1

Heat treatment

Overall heat treatment in a furnace , 500℃ to 560℃

2

Flaw detection

100% Flaw detection

3

Hydrostatic test

2.66MPa

4

Magnaflux

Aim at welding place flaw detection can not cover

Manhole (As customer's requirement )

1

Quantity

1 ; On top

Safety Valve (As customer's requirement )

1

Quantity

Two

2

Location

On the top of tanker ;

3

Type

Only weld suitable flange

4

Size

As customer's  requirement

Liquidometer (As customer's requirement )

1

Quantity and Model

1

2

Location

On left side of tanker

3

Type

Only weld suitable flange

4

Size

As customer's requirement

Valve and pipe Detail (As customer's requirement )

Running System

1

Axles

3

13 TON FUWA Axles

2

Suspension system

1

FUWA Air suspension

3

Wheel rim

12

8.25*22.0

4

Tyre

12

Brand : Triangle,425/65R22.5

5

Kingpin

1

JOST2",bolt on ,in rubbing plate

6

Landing legs

2

JOST D200  single linkage,Gear type

Pneumatic Brake System

1

Spring brake chamber

6

FUWA

2

Air connector

2

FUWA

3

Relay Valve

1

BRAND：WABCO

4

ABS

1

KEMI ABS

Electronical System

1

7-Pin Socket

1

24V 7-pin socket

2

LED Lamp

1

All kinds of lamp

3

Cable

1

Stander cable

Accessories

1

Small Tool box

1

2

Wheel carrier

1

3

Fire extinguisher

2

With red box

4

Cabinet

1

5

Plastic fender

6

6

Static conductive belt

1

7

Impeller blasting

1

Completely

8

Paint

1

As customer requirements
