Total Weight

17000kg

Dimension (L*W*H)

14750*3843*2347 mm

Laser power

12000W

Working area for metal sheet

6000*2500mm

Y-axis stroke

6000mm

X-axis stroke

2500mm

Z-axis stroke

290mm

X/Y axis position accuracy

±0.03mm

X/Y axis reposition accuracy

±0.02mm

Total power with 12000W

76KW (Total current: 200A)

Max. Moving speed

200m/min

Maximum acceleration

2.5G

Work platform exchange time

15-17 s

Max. Working capacity of sheet table

3500kg

Specified voltage and frequency

380V/50Hz/60Hz/60A

Continuous working time

24hrs
